Magnification Correction (3)
The SP modes settings for the paper library are:
2950: Side 1 main scan
2951: Side 1 sub scan
2952: Side 2 main scan
2953: Side 2 sub scan
Range: -0.8% to +0.8%
There are settings for custom papers 001 to 100.
These settings allow correction for the different
amounts of paper shrinkage that occur with
different types of paper.
Note that the SP has a range of -0.8% to +0.8%. However, the user tool has a
range of -0.5% to +0.5%. If the technician adjusts to, for example, 0.6%, this
setting will remain unless the customer adjusts it, then it will fall between -0.5%
to +0.5%.
