Taurus-C1 Training
264
Slide 264
Image Position Correction (MUSIC)
What does MUSIC do?
Three MUSIC sensors above the ITB read MUSIC
sensor patterns that the machine makes on the
ITB.
When the alignment of vertical lines (or intervals
between lines) in a MUSIC pattern are not
correct, this can cause color registration errors.
The machine adjusts the start timing for the laser
at the start of the main scan.
If skew is detected in the main scan direction
(front to rear), the machine can change the angle
of Lens 2 with a motor.
MUSIC is "Mirror Unit for Skew and Interval Correction".
