Cleaning the Roll Holder and Guide Groove
Remove dust in the roll holder/spool holder rail groove using an item such as an air duster.
Cleaning the Platen
The platen is susceptible to becoming dirty with bits of media. Also, if ink is affixed to the platen, it may
not be possible to successfully feed media when printing. If the platen is dirty, clean it.
• Allow the temperature of the platen to cool sufficiently before cleaning it.
• The grooves of the media guides are a particularly susceptible location for dirt to build up. Clean
the grooves sufficiently.
1. Open the center cover.
2. Daily Care and Maintenance
28
