3. ADF cover open sensor [A] ( x 1, x 1)
ADF Feed Sensor
1. ADF unit ( p.31)
2. ADF feed unit ( p.32)
3. Sensor cover [A] ( x 2)
4. Replacement and Adjustment
38
4
