Ricoh SP 311SFNw - Printer Problems

1. Open the ADF cover.
CVW054
2. Gently pull the jammed original to remove it. Be careful not to pull the original too hard,
as it may rip.
CVW055
3. Close the ADF cover.
4. Lift the ADF, and if there is original remaining in the ADF, gently pull the jammed original
to remove it.
Be careful not to hold the input tray when lifting the ADF, for the tray might be damaged.
CVW057
5. Close the ADF.
10. Troubleshooting
222
