11
19. Execute WPS (PIN system) from the router (access point)’s
web page.
20. Check the result.
Connection has succeeded:
• Press the [Menu] key to return to the initial screen.
Connection has failed:
• Press the [Back] key to return to the screen displayed in Step
16.Checkthecongurationfortherouter (accesspoint),then
try the connection again.
21. Configuring the Wi-Fi settings is complete.
Control Panel Sheet
DUE130
1
2 3 4 5 6 78
10 11
9
12
1 [Wi-Fi Direct] key 7 [Back] key
2 [Stop/Start] key 8 NFC tag
3 [Job Reset] key 9 [Power] key
4 [Menu] key 10 Data In Indicator
5 Display 11 Alert Indicator
6 Scroll Keys 12 [OK] key
For safe and correct use, please be sure to read the Safety Information before using the machine.
