2.4 Seat Clamp Assembly:
• Slide saddle into seat post clamp.
• Using a 6mm hex wrench. Tighten the bolt to 16-17nm of torque.
• The seat post angle is adjustable. Make sure the grooves are properly aligned. Ensure the bolt
is correctly torqued. If left loose or over-tightened, the seat post bolt could snap causing
serious injury and/or death.
NOTE:
◆
SOME GENERATIONS COME WITH THE SEAT POST SEPARATE FROM THE SADDLE. IF
ALREADY JOINED, CHECK THAT THE TORQUE ON THE BOLT IS TO 16-17 NM SPEC.
2.5 Pedal Assembly:
• Applying grease to the spindles of the bottom bracket will help ensure the crank arms fully seat and
do not make noise while you are riding.
• The left pedal (marked “L”) must be installed in the left crank arm. It is reverse thread, rotate
counterclockwise to install and tighten.
• Screw each pedal into a crank by hand. They should screw in easily to start. Do not force them.
