RIDGID 916 - Table I Standard Roll Groove Specification

916 Roll Groover
Ridge Tool Company14
CARBON STEEL OR STAINLESS STEEL
ALUMINUM PIPE OR TUBE PIPE OR TUBE PVC PIPE
Pipe Size Wall Thickness Wall Thickness Wall Thickness
Min. Max. Min. Max. Min. Max.
1″ .065 .133 .065 .109 .133 .133
1
1
/
4
″ .065 .140 .065 .140 .140 .140
1
1
/
2
″ .065 .145 .065 .145 .145 .200
2″ .065 .154 .065 .154 .154 .218
2
1
/
2
″ .083 .203 .083 .188 .203 .276
3″ .083 .216 .083 .188 .216 .216
3
1
/
2
″ .083 .120 .083 .188 .226 .226
4″ .083 .120 .083 .188 .237 .237
5″ .109 .134 .109 .188 .258 .258
6″ .109 .134 .109 .188 .280 .280
Table II. Pipe Maximum and Minimum Wall Thickness
NOTE! All Dimensions are in Inches.
Table I. Standard Roll Groove Specifications
1
NOTE! All Dimensions are in Inches.
NOM. PIPE MIN. GASKET GROOVE GROOVE NOM.
PIPE DIAMETER WALL SEAT WIDTH DIAMETER GROOVE DEPTH
SIZE O.D. TOL. THK. +.015/-.030 +.030/-.015 O.D. TOL. REF
2
1 1.315 +.013 .065 .625 .281 1.190 +.000 .063
-.015 -.015
1
1
/
4
1.660 +.016 .065 .625 .281 1.535 +.000 .063
-.015 -.015
1
1
/
2
1.900 +.019 .065 .625 .281 1.775 +.000 .063
-.015 -.015
2 2.375 +.024 .065 .625 .344 2.250 +.000 .063
-.016 -.015
2
1
/
2
2.875 +.029 .083 .625 .344 2.720 +.000 .078
-.016 -.015
3 OD 3.00 +.030 .083 .625 .344 2.845 +.000 .078
-.018 -.015
3 3.50 +.030 .083 .625 .344 3.344 +.000 .078
-.018 -.015
3
1
/
2
4.00 +.030 .083 .625 .344 3.834 +.000 .083
-.018 -.015
4 4.50 +.035 .095 .625 .344 4.334 +.000 .083
-.020 -.015
4
1
/
2
5.00 +.040 .095 .625 .344 4.834 +.000 .083
-.020 -.015
5 5.563 +.050 .109 .625 .344 5.395 +.000 .084
-.022 -.015
6 OD 6.00 +.050 .109 .625 .344 5.830 +.000 .085
-.022 -.015
6 6.625 +.050 .109 .625 .344 6.455 +.000 .085
-.024 -.015
1. AS per AWWA C606-87
2. Nominal Groove Depth is provided as a reference dimension. Do not use groove depth to determine acceptability.
