Standard Equipment
Grooving Roll.................1
1
/
4
″- 6″ (1
1
/
4
″ -3″ Schedule 40,
6″ Schedule 10)
Driving Roll ....................1
1
/
4
″ - 6″ (1
1
/
4
″ -3″ Schedule 40,
6″ Schedule 10)
Feed Handle..................Tubular Design
Drive Bar Adapter..........(When Required)
916 Roll Grooving Models
Roll Groover Assembly
Instructions
WARNING
The 916 Roll Groover should only be used with the
following power drives and threading machines.
• 300 Power Drive (38 and 57 RPM)
• 535 Threading Machine (38 and 54 RPM)
• 1822 Threading Machine
• 535 Automatic Threading Machine
• 300 Compact Machine
Use only power drives and threading machines
that operate at 58 RPM or less. Higher speed
machines increase risk of injury.
To prevent serious injury, proper assembly of the
Roll Groover is required. The following procedures
should be followed:
Installing on No. 300 Power Drive
1. Remove carriage or other attachments from the 300
Power Drive.
2. Fully open front chuck of power drive.
Description, Specifications,
Standard Equipment and
Accessories
Description
The RIDGID Model No. 916 Roll Groover forms standard
roll grooves in steel, stainless steel and aluminum pipe.
The No. 916 is a portable lightweight roll groover designed
for 1
1
/
4
″ - 6″ Schedule 10 pipe (1
1
/
4
″ - 3″ Schedule 40
pipe); also can be adapted for 1″ Schedule 10, 1″ Schedule
40, 2″ - 6″ copper types K, L, M, and DWV with a roll
change. The grooves are formed by a grooving roll fed into
a drive roll to the specifications required for mechanical
coupling systems. The only adjustment needed is for the
depth of the groove.
The No. 916 Roll Groover is designed for specific use with
the RIDGID No. 300 Power Drive, 300 Compact, 535M,
535A and 1822-I Threading Machines. Different 916
models are
required
for every power source or mounting
operation.
When properly used, the Model 916 makes
grooves that are dimensionally within the specifications
of AWWA C606-87. Selection of appropriate materials
and joining methods is the responsibility of the system
designer and/or installer. Before any installation is
attempted, careful evaluation of the specific service
environment, including chemical environment and ser-
vice temperature, should be completed.
Specifications
Roll Grooving Capacity
•1
1
/
4
″ - 6″ Schedule 10
•1
1
/
4
″ - 3″ Schedule 40
(See Table II for Wall Thickness)
•2″ - 6″ Copper Types (K,L,M, DWV)
•1″ Schedule 10
•1″ Schedule 40
Depth Adjustment .......Adjustment Screw
Actuation......................Integral Single Stroke Handle
Mechanism
Power Drive
Mounting ......................300 Power Drive, 1822 -I
Threading Machine, 535M,
535A Threading Machines,
300 Compact Threading
Machine
Weight..........................33 lbs.
916 Roll Groover
Ridge Tool Company4
CAUTION
Catalog Model Weight
No. No. Description lb. kg.
45007 916 Roll Groover for 300 Power Drive 33 15,0
46852 916 Roll Groover for Copper Tubing for 300 P.D. 34 15,5
60382 916 Roll Groover for 535 33 15,0
48307 916 Roll Groover for 1822 33 15,0
48307 916 Roll Groover for 300 Compact Mounted on 100, 33 15,0
150 and 200 Stands
45007 916 Roll Groover for 300 Compact Mounted on 33 15,0
250 Stand (Also requires 67662 Adapter Bracket)
Accessories
45347 — Roll Set for 1″ Schedule 10, 40 (Optional) 6 2,6
45352 — Roll Set for Copper (Optional) 6 2,6
69667 — Roll Set for 1
1
/
4
″ - 1
1
/
2
″ AWWA (Optional) 6 2,6
69692 — Roll Set for 2″ - 6″ AWWA (Optional) 6 2,6
67662 — Adapter Bracket for 300 Compact 30 13,6
76822 — English Diameter Tape 0.3 0,1
76827 — Metric Diameter Tape 0.3 0,1
