MediorNet User Manual 2.00.0
ARTIST Panel Ports
The ARTIST-Panel Ports are used to connect Artist panels to the MediorNet Frame. At each Frame, two Artist-
Panels can be connected at the same time. One Artist-Panel can be connected via CAT5, one via BNC.
Use an X-over cable between the Artist Card “CAT5-108 G2 RC” and the ARTIST-Panel Port 1 to
connect an Artist-Mainframe at the MediorNet Frame.
Use a straight-through cable to connect an Artist-Panel at the ARTIST-Panel Port 1.
For the ARTIST-Panel Ports the 2 channel mode is supported.
1 8
Pin
Signal
1
RxD+
2
RxD-
3
TxD+
4
--
5
--
6
TxD-
7
--
8
--
Z = 110 Ω
Figure 15: MN-XSS Card ARTIST panel 1 Port RJ45 pinout
2
1
Pin
Signal
1
TxRx+
2
TxRx-
Z = 75 Ω
Figure 16: MN-XSS Card ARTIST panel 2 Port BNC pinout
