MediorNet User Manual 2.00.0
MN-XSS Artist STATUS
The contents in the tab Artist 1 (RJ45) and Artist 2 (BNC) are identical.
Figure 234: MN-XSS Artist STATUS
The meanings of the different fields are described in the table below:
Channel
Identifier for the AES Channel / single Audio SubChannels
Name
Name of the AES Channel / single Audio SubChannels
Audio detected
detected Audio signal
Plug Type
Type of physical connector
Direction
Signal direction: In- / Output
Connection State
Icon about state of connection
