Riedex DM-250 - E Lectrical Installation

10
ElEctrIcal connEctIon2.2
The extraction unit requires a 400 V, 50 Hz three-phase power
supply with zero and ground to function. A fuse with class
K16A must be used.
SWITCH BOX
Transformator
Fuses
Duration
Reset fan
Reset cleaning (on DM-200/M)
4
1
2
3
5
O / position for automatic operation
Cleaning switched on
Thermal fault indicator light
Pressure dierence indicator light
Main switch/Emergency-o
= switch o power
Start
6
1
2
3
4
5
dEscrIptIon of thE machInE
BEDEUTUNG
Funktion
Ort
LAYOUT ZEICHNUNG - MONTAGEPLATTE ANZICHT
