Riedex DM-250 - 3 S Afety

13
Typ
Seriennr.
Baujahr
Nennvolumenstrom (m³/h)
Durchmesser (mm)
Unterdruck bei Vnenn am Stutzen (Pa)
Motorleistung (kW)
Nenndrehzahl (U/min.)
Nennstrom (A)
Nenn Betriebspannung (V)
Stromart
Frequenz (Hz)
Vorsicherung (A)
Gewicht (kg)
DM-350
350001
2018
6927
350
2100
11
2890
20
400
3-Phasen
50
32
900
ENTSTAUBER
DUST EXTRACTION SYSTEMS
Type DM-250
Serial no. 250001
Construction year 2019
Air ow (min.) (m/h) 3534
Inlet diameter (mm) 250
Pressure at inlet (Pa) 2100
Motor (kW) 5,5
Rotations per minute (RPM) 2890
Current (A) 10,5
Voltage (V) 400
Current type 3-phase
Frequency (Hz) 50
Pre-fuse (A) 16
Weight (kg) 580
Noise level 70 dB(A)
DUST EXTRACTION UNIT
3.0 safeTy
The extraction unit meets all the relevant safety regulations and has, therefore, been awarded the CE
mark. Various technical measures have been taken in accordance with the CE guidelines and harmoni-
zed standards so that the extraction unit meets the safety requirements based on the current state of
technology.
The manufacturer has carried out a risk analysis in accordance with NEN EN 1050 and produced a tech-
nical construction le for the extraction unit.
CORRECT USE
The extraction unit is exclusively intended for the extraction of dry wood dust and wood chips. Other
materials other than wood may not be extracted. Operational reliability is only guaranteed with proper
use of the machine.
Mounted on the unit is a CE-marked type plate with technical specications (see gure 2.).
Proper operation and separation quality are guaranteed if the extraction unit is properly connected to
one or more woodworking machines and if used properly. When extracting a dust-tested machine with a
dust source, it was determined that the maximum workplace concentration TRK value of 2 mg/m is not
exceeded.
safEty
Accidents are often caused by a succession of spe-
cial and deviating circumstances from the normal
situation. If a deviating, unsafe or special circum-
stance occurs, rectify this rst.
NOTE
Any other use is not intended use. Use other than
in accordance with the regulations will invalidate
the warranty and disclaim all liability on the part
of the manufacturer. The user is liable for all da-
mage to third parties and their property.
NOTE
Figure 2. Type plate.
