Riello Array AR 3000 User Manual

60
SHUTDOWN
60
APPENDIX
Menu item Sub item / Parameter Range Default Value Units User level
(187) Prog. Output 5.
0) Disabled
1) General Pump
2) CH Pump
3) DHW Pump
4) System Pump
5) Cascade Pump
6) Alarm Relay
7) Filling Valve
8) LPG Tank
9) External Igniter
10) Air Damper
14) Alarm Burner CC
15) Status Burner CC
16)Zone pump
17)Mixing valve open
18)Mixing valve closed
19)Anti-legionella pump
*See Appliance
settings
2: Installer
(129) Flow Sensor
Bitron, Huba: DN8, DN10,
DN15, DN15, DN20, DN25
Huba DN25 2: Installer
(130) Flow Scaling Factor 0…25.5 3.2 rpm/l 2: Installer
(131) Min Pressure Off, 0.3…5.0 0.1 bar 2: Installer
(132) Pressure Fill Hyst. 0.2…5.0 0.5 bar 2: Installer
(133) Mod. Pump dT 5…40 15 °C 2: Installer
(134) Mod. Pump Start Time 0…255 120 Sec. 2: Installer
(135) Mod. Pump Type
0. Wilo Yonos
1. Salmson
2. Grundfos
Grundfos 2: Installer
(136) Mod. Pump Mode
0. On/Off
1. Modulating
2-10 Fixed 20… 100%
Modulating 2: Installer
(137) Mod. Pump Min Power 0…100 30 % 2: Installer
(138) Appliance Type 50…55 50 2: Installer
(139) Dair active Yes, No No 2: Installer
(140) Minimal Flow 0.0…100 17 l/min 2: Installer
(107) Anti-legionella Day Sun…Sat. Sun Day 2: Installer
(108) Anti-legionella Hour 0…23 0 Hour 2: Installer
(183) High Limit Test Simulated/Physical Simulated 3: Factory
(205) Dep. Zone Control Disabled/Enabled Disabled 1: User
(155) Frost Protection 10…30 15 °C 2: Installer
(186) Frost protection outdoor -30...15 5 °C 2:Installer
Module Cascade Settings
(72) Permit Emergency Mode Yes/No Yes 1: User
(74) Emergency Setpoint 20…90 70 °C 2: Installer
(75) Delay Per Start Next Dep 5…255 120 Sec. 2: Installer
(76) Delay Per Stop Next Dep 5…255 30 Sec. 2: Installer
(142) Delay Quick Start Next 5…255 60 Sec. 2: Installer
(143) Delay Per Quick Stop Next 5…255 15 Sec. 2: Installer
(77) Hyst Down Start Module 0…40 5 °C 2: Installer
(78) Hyst Up Stop Module 0…40 4 °C 2: Installer
(144) Hyst Down Quick Start 0…40 20 °C 2: Installer
(145) Hyst Up Quick Stop 0…40 6 °C 2: Installer
(146) Hyst Up Stop All 0…40 8 °C 2: Installer
(147) Number of Units
1…16 (basic cascade) 1…8
(full cascade)
8 2: Installer
(148) Power Mode
0) Disabled
1) Min burners
2) Max burners
3) Balanced burners
2 2: Installer
(79) Max. Setp. Offset Down 0…40 2 °C 2: Installer
