APPENDIX
Menu item Sub item / Parameter Range Default Value Units User level
(80) Max Setp Offset Up 0…40 5 °C 2: Installer
(81) Start Mod Delay Fact 0…60 60 Min. 2: Installer
(82) Next Module Start Rate 10…100 80 % 2: Installer
(83) Next Module Stop Rate 10…100 25 % 2: Installer
(84) Module Rotation Interval 0…30 1 Days 2: Installer
(149) First Module to Start 1…16 1 2: Installer
(86) MC PID P 0…1275 50 3: Factory
(87) MC PID I 0…1275 500 3: Factory
(150) MC PID Slew Rate Up 0…25.5 1.0 3: Factory
(151) MC PID Slew Rate Dn 0…25.5 1.0 3: Factory
(152) PwrMode2 Min Power 0…100 20 % 2: Installer
(153) PwrMode2 Hysteresis 0…100 40 % 2: Installer
(154) Post-Pump period 0…255 60 Sec. 2: Installer
(184) N. active burner for DHW 0…16 16 2:Installer
Boiler Cascade Settings
(73) Boiler Address
Stand-alone (0)
Managing (1)
Dependent (2...8)
Stand-alone 2: Installer
(156) Permit Emergency Mode Yes/No Yes 1: User
(157) Emergency Setpoint 20…90 70 °C 2: Installer
(158) Delay Per Start Next Blr. 0…1275 1275 Sec. 2: Installer
(159) Delay Per Stop Next Blr. 0…1275 1275 Sec. 2: Installer
(160) Delay Quick Start Next 0…1275 400 Sec. 2: Installer
(161) Delay Quick Stop Next 0…1275 240 Sec. 2: Installer
(162) Hyst Down Start Boiler 0…40 5 °C 2: Installer
(163) Hyst Up Stop Boiler 0…40 2 °C 2: Installer
(164) Hyst Down Quick Start 0…40 10 °C 2: Installer
(165) Hyst Up Quick Stop 0…40 4 °C 2: Installer
(166) Hyst Up Stop All 0…60 8 °C 2: Installer
(167) Number of boilers
1…16 (basic cascade) 1…8
(full cascade)
1 2: Installer
(168) Power Mode
0) Disabled
2) Max burners
3) Balanced burners
2 2: Installer
(169) Max. Setp. Offset Down 0…40 2 °C 2: Installer
(170) Max Setp Offset Up 0…40 5 °C 2: Installer
(171) Start Mod Delay Fact 0…60 40 Min. 2: Installer
(172) Next Boiler Start Rate 10…100 80 % 2: Installer
(173) Next Boiler Stop Rate 10…100 25 % 2: Installer
(174) Boiler Rotation Interval 0…30 5 Days 2: Installer
(175) First Boiler to Start 1…8 - 2: Installer
(176) BC PID P 0…1275 25 3: Factory
(177) BC PID I 0…1275 1000 3: Factory
(178) BC PID Slew Rate Up 0…25.5 1.0 3: Factory
(179) BC PID Slew Rate Dn 0…25.5 1.0 3: Factory
(180) PwrMode2 Min Power 0…100 20 % 2: Installer
(181) PwrMode2 Hysteresis 0…100 40 % 2: Installer
(182) Post-Pump period 0…255 30 sec 2: Installer
