3.1 Structure of the MENU tree of the REC10CH
MENU
DEFAULT VALUE FACTORY
SET
MINIMUM
VALUE
MAXIMUM
VALUE
ACCESS LEVEL
NOTES
SET
VALUE
SETTINGS USER
TIME & DATE USER
DAYLIGHT SAVINGS TIME FUNCTION ACTIVE FUNCTION NOT ACTIVE FUNCTION ACTIVE USER
LANGUAGE ENGLISH / ITALIANO / ... USER
BACKLIGHT 5 min 1 min 15 min USER
TIME SCHEDULE USER
MAIN USER: only if POR = 1
ZONE 1
USER: only if POR = 1 and zone
added
ZONE 2
USER: only if POR = 1 and zone
added
DHW
USER: only if PLANT
CONFIGURATION = WATER TANK
HP DHW
USER: only if HP present and
USE PER DHW active
TECHNICAL INSTALLER
INSTALLATION INSTALLER
ZONES MANAGER INSTALLER
MODIFY ZONE MAIN MAIN / ZONE 1 / ZONE 2 INSTALLER
ACTUATION TYPE
ITRF05/boiler card ITRF05/boiler card BE16 INSTALLER: only MAIN zone
REQUEST TYPE THERMOSTAT
THERMOSTAT / TEMPERAURE PROBE / REC10CH
MASTER / REC10CH SLAVE
INSTALLER
BE16 ADDRESS
-- 1 6
INSTALLER: only zones with
ACTUATION=BE16
HYDRAULIC CONF
DIRECT ZONE DIRECT ZONE MIXING ZONE
INSTALLER: only zones with
ACTUATION=BE16
ZONE TYPE HIGH TEMP HIGH TEMP LOW TEMP INSTALLER
MIN CH SET
20°C (HT)
20°C (LT)
20°C MAX CH SET INSTALLER
MAX CH SET
80.5 °C (HT)
45°C (LT)
MIN CH SET
80.5 °C (HT)
45°C (LT)
INSTALLER
CHANGE NAME INSTALLER
PI - PROPORTIONAL
5 0 99
SERVICE: only mixing zones with
ACTUATION=BE16
PI - INTEGRAL
10 0 99
SERVICE: only mixing zones with
ACTUATION=BE16
VALVE RUN
120 sec 0 sec 120 sec
SERVICE: only mixing zones with
ACTUATION=BE16
CLOSING AT POWER ON
140 sec 0 sec 240 sec
SERVICE: only mixing zones with
ACTUATION=BE16
OUTLET OVER
55°C 0°C 100°C
SERVICE: only LT zones with
ACTUATION=BE16
OUTLET OVER TEST TIME
0 min 0 min 240 min
SERVICE: only LT zones with
ACTUATION=BE16
OUTLET OVER WAIT TIME
2 min VALVE RUN 240 min
SERVICE: only LT zones with
ACTUATION=BE16
OUTLET OVER REST TIME
2 min 0 min 240 min
SERVICE: only LT zones with
ACTUATION=BE16
FREEZE PROT TEMP
6°C -10°C 50°C
SERVICE: only zones with
ACTUATION=BE16
FREEZE PROT OFFSET
5°C 1°C 20°C
SERVICE: only zones with
ACTUATION=BE16
FREEZE PROT T EXT
10°C 0°C 100°C
SERVICE: only zones with
ACTUATION=BE16
POR 0 (1 if REC10 in the AMBIENT) 0 1 INSTALLER
ADD ZONE INSTALLER
DELETE ZONE INSTALLER
SENSOR CALIBRATION 0.0°C - 6.0°C 6.0°C INSTALLER
SYSTEM RESET INSTALLER
PARAMETERS INSTALLER
ANTI-CYCLE FUNCTION 3 min 0 min 20 min INSTALLER
HYST ON HIGH TEMP 5°C 2°C 10°C SERVICE
HYST OFF HIGH TEMP 5°C 2°C 10°C SERVICE
HYST ON LOW TEMP 3°C 2°C 10°C SERVICE
HYST OFF LOW TEMP 3°C 2°C 10°C SERVICE
SP INCR HIGH TEMP 5°C (0°C if instantaneous boiler) 0°C 10°C SERVICE
SP INCR LOW TEMP 0°C 0°C 6°C SERVICE
