Riester ri-scope - Battery Handles and Startup; 2.1. Purpose and Indication; Battery Handle Types; 2.6.1. ri-accuUSB Technology

19
2.2. Battery handle range
All instrument heads described in this manual fit the following battery handles
and can therefore be combined individually. All instrument heads also fit on the
handles of the wall model ri-former®.
ATTENTION!
LED instrument heads are only compatible with a specific serial number of the
ri-former® diagnostic station. Information about the compatibility of your diag-
nostic station is available on request.
2.3. Battery handle type C with rheotronic
®
2.5 V
To operate these battery handles, you need 2 standard alkaline batteries type
C Baby (IEC standard LR14) or a ri-accu® 2.5 V. The handle with the ri-accu®
from Riester can only be charged in the Riester ri-charger® charger.
2.4. Battery handle type C with rheotronic
®
3.5 V (for ri-charger® L)
To operate this battery handle you will need:
- 1 rechargeable battery from Riester with 3.5 V (art. no. 10691 ri-accu® L).
- 1 charger ri-charger® L (art. no. 10705, art. no. 10706)
2.5. Battery handle type C with rheotronic
®
3.5
For charging in the wall socket 230 V or 120 V
To operate this socket handle you will need:
- 1 rechargeable battery from Riester with 3.5 V (art. no. 10692 ri-accu® L)
2.6. Battery handle type C with rheotronic
®
3.5 V (for plug-in charger)
To operate this battery handle you will need:
-1 rechargeable battery from Riester with 3.5 V (art. no. 10694 ri-accu® L).
-1 Plug-in charger (art. no. 10707)
New ri-accu®USB
2.6.1 art. no. 10704
Battery handle type C with rheotronic
®
3.5V and with ri-accu®USB char-
ging technology includes:
- 1 rechargeable battery from Riester with 3.5 V (art. no. 10699 ri-accu®USB)
- 1 handle type C Rheotronik
- 1 USB cabel Typ C, charging is possible with any DIN EN 60950 /DIN EN
62368-1 compliant USB source without patient contact (2 MOOP). Riester
offers an optional medically approved power supply under art. no. 10709.
Function:
Instrument head with battery handle type C and ri-accu®USB is ready for use
during charging.
It can therefore be used during a patient examination while it is charging.
ATTENTION!
Takes place during charging (battery handle type C with USB charging tech-
nology art. no. 10704), if the medical power supply of Riester art. no. 10709 is
used, since this ME system is tested in accordance with standard IEC 60601-1:
2005 (Third Edition) + CORR. 1:2006 + CORR. 2: 2007 + A1: 2012 and is medically
approved.
This ri-accu®USB has a charge status indicator.
LED is green: - Battery is fully charged.
LED flashes green: - Battery is being charged.
LED is orange: - Battery is too weak and must be charged.
- Specifications:
18650 Li-ion Battery, 3.6 V 2600 mAh 9.62 Wh
Ambient temperature: 0° to +40°
Relative humidity: 30 % to 70 % non-condensing
Transport and storage temperature: -10 ° to +55 °
Relative humidity: 10 % to 95 % non-condensing
Air pressure: 800 hPa - 1100 hPa
Operating environment:
The ri-accu®USB is used exclusively by professional users in clinics and me-
dical practices.
2.7. Battery handle type AA with rheotronic
®
2.5 V
To operate these battery handles, you need 2 standard alkaline batteries type
AA (IEC standard LR6)
2.8. Battery handle type C with rheotronic
®
3.5 V (for ri-charger® L)
To operate this battery handle you will need:
- 1 rechargeable battery from Riester with 3.5 V (art. no. 10694 ri-accu® L).
- 1 charger ri-charger® L (art. no. 10705, art. no. 10706)
3. Commissioning (inserting and removing batteries and rechargeable bat-
teries)
ATTENTION!
Use only the combinations described under 2.3 to 2.8!
3.1. Inserting the batteries:
Battery handles (2.3 and 2.7) type C and AA with rheotronic
®
2.5 V:

 ChargenCode

 Seriennummer 4
 AchtungBedienungsanleitungbeachten

2.Batteriegriffe
2.1.Zweckbestimmung/Indikation
DieindieserGebrauchsanweisungbeschriebenenRiesterBatteriegriffedienenzur
VersorgungderInstrumentenköpfemitEnergie(dieLampensindindenentsprechendenInstrumentenköpfen
enthalten).SiedienenferneralsHalter.

2.2.BatteriegriffeSortiment
DerindieserGebrauchsanweisungbeschriebeneInstrumentenkopfpasstauffolgende
Batteriegriffeundkannsomitindividuellkombiniertwerden.DieserInstrumentenkopfpasst
ferneraufdieGriffedesWandmodellsriformer®.

ACHTUNG!
LEDInstrumentenköpfesinderstabeinerbestimmtenSeriennummerderDiagnosestationriformer®
kompatibel.AngabenüberdieKompatibilitätIhrerDiagnosestationerhaltenSiegerneaufAnfrage.

Fürriscope®LOtoskope,riscope®LOphthalmoskope,perfect,H.N.O,praktikant,deluxe®,Vet,Retinoskope
Slit,Spot,rivision®undEliteVue:

2.3.BatteriegriffTypCmitrheotronic®2,5V.UmdieseBatteriegriffezubetreiben,benötigenSie
2handelsüblicheAlkalineBatterienTypCBaby(IECNormbezeichnungLR14)odereinenriaccu®
2,5V.DerGriffmitdemriaccu®vonRiesterkannnurimLadegerätricharger®vonRiester
geladenwerden.

2.4.BatteriegriffTypCmitrheotronic®3,5V(fürricharger®L)
UmdiesenBatteriegriffzubetreibenbenötigenSie:
1AkkuvonRIESTERmit3,5V(Art.Nr.10691riaccu®L).
1Ladegerätricharger®L(Art.Nr.10705,Art.Nr.10706)

2.5.BatteriegriffTypCmitrheotronic®3,5VzumLadeninderSteckdose230Voder120V
UmdiesenSteckdosengriffzubetreibenbenötigenSie:
1AkkuvonRIESTERmit3,5V(Art.Nr.10692riaccu®L).

2.6.BatteriegriffTypCmitrheotronic®3,5V(fürSteckerladegerät)
UmdiesenBatteriegriffzubetreibenbenötigenSie:
1AkkuvonRIESTERmit3,5V(Art.Nr.10694riaccu®L).
1Steckerladegerät(Art.Nr.10707).

Neu riaccu®USB

2.6.1Art.Nr.10704
BatteriegriffTypCmitrheotronic®3,5Vundmitriaccu®USBLadetechnik
enthält:
1AkkuvonRIESTERmit3,5V(Art.Nr.10699riaccu®USB)
1GriffTypCRheotronik
1USBKabelTypC,hierhabensiedieMöglichkeitdenAkkuz.B.anihremHandyNetzteiloderComputerzu
laden.OptionalbietetRIESTEReinMedizinischzugelassenesNetzteilmitderArt.Nr.10709an.
