RIGOL Chapter 5 Specifications
5-4 DG1000Z User’s Guide
FSK
Carrier Waveform Sine, Square, Ramp, Arb (except DC)
Source
Internal/External
Modulating Waveform
Square with 50% duty cycle
Key Frequency
2mHz to 1MHz
PSK
Carrier Waveform Sine, Square, Ramp, Arb (except DC)
Source Internal/External
Modulating Waveform
Square with 50% duty cycle
Key Frequency
2mHz to 1MHz
PWM
Carrier Waveform Pulse
Source Internal/External
Modulating
Waveforms
Sine, Square, Ramp, Noise, Arb
Width Deviation 0% to 100% of Pulse Width
Modulating Frequency 2mHz to 1MHz
[Mod/Trig/FSK/Sync] Input
Input Range
75mVRMS to ±5Vac+dc
Input Bandwidth 50kHz
Input Impedance 10kΩ
Burst Characteristics
Carrier Waveform
Sine, Square, Ramp, Pulse, Noise, Arb (except DC)
Carrier Frequency 2mHz to 25MHz 2mHz to 30MHz 2mHz to 60MHz
Burst Count 1 to 1,000,000 or Infinite
Start/Stop Phase 0° to 360°, 0.1° resolution
Internal Period 1μs to 500s
Gated Source
External Trigger
Trigger Source
Internal, External or Manual
Trigger Delay
0ns to 100s
Sweep Characteristics
Carrier Waveform
Sine, Square, Ramp, Arb (except DC)
Type
Linear, Log or Step
Direction
Up/Down
Start/Stop Frequency
Consistent with the upper/lower limit of the frequency of
the carrier waveform
Sweep Time
1ms to 500s
Hold/Return Time 0ms to 500s
Trigger Source Internal, External or Manual
Mark Falling edge of the Sync signal (programmable)
