RIGOL Appendix Test Record Form
2 DM3058/DM3058E Performance Verification Guid
DC Gain
Function
[1]
Range
Test
signal
Quick
Test
1-year Test Limit
Test
Result
Upper Limit Lower Limit
DC Voltage
200.000 mV
200 mV
200.038 mV
199.962 mV
200.000 mV
-200
mV
-199.962 mV -200.038 mV
2.00000 V
2 V
Q
[5]
2.00036 V
1.99964 V
2.00000 V
-2 V
Q
-1.99964 V
-2.00036 V
20.0000 V
20 V
Q
20.0038 V
19.9962 V
20.0000 V
-20 V
Q
-19.9962 V
-20.0038 V
200.000 V
200 V
200.036 V
199.964 V
200.000 V
-200 V
-199.964 V
-200.036 V
1000.00 V
1000 V
1000.19 V
999.81 V
1000.00 V
-1000 V
-999.81 V
-1000.19 V
DC
Current
[2]
200.000 μA
200 μA
Q
200.120 μA
199.880 μA
200.000 μA
-200 μA
Q
-199.880 μA
-200.120 μA
2.00000 mA
2 mA
2.00120 mA
1.99880 mA
2.00000 mA
-2 mA
-1.99880 mA
-2.00120 mA
20.0000 mA
20 mA
Q
20.0230 mA
19.9770 mA
20.0000 mA
-20 mA
Q
-19.9770 mA
-20.0230 mA
200.000 mA
200 mA
200.156 mA
199.844 mA
200.000 mA
-200
mA
-199.844 mA -200.156 mA
2.00000 A
2 A
Q
2.00380 A
1.99620 A
2.00000 A
-2 A
-1.99620 A
-2.00380 A
10.0000 A
10 A
10.0260 A
9.9740 A
10.0000 A
-10 A
-9.9740 A
-10.0260 A
Resistance
[3]
200.000 Ω
200 Ω
200.070 Ω
199.930 Ω
2.00000 kΩ
2 kΩ
Q
2.00046 kΩ
1.99954 kΩ
20.0000 kΩ
20 kΩ
20.0046 kΩ
19.9954 kΩ
200.000 kΩ
200 kΩ
200.046 kΩ
199.954 kΩ
2.00000 MΩ
2 MΩ
Q
2.00088 MΩ
1.99912 MΩ
10.0000 MΩ
10 MΩ
10.0253 MΩ
9.9747 MΩ
100.000 MΩ
[4]
100 MΩ
101.754 MΩ
98.246 MΩ
Note
[1]
: The reading rate is set to "Slow".
Note
[2]
: For continuous currents greater than DC 7A or AC RMS 7A, close the circuit for 30 s and
then open the circuit for 30 s.
Note
[3]
: Specifications are for the 4-wire resistance function or the 2-wire resistance function using
“REL” operation. If the 2-wire resistance function is used without "REL" operation, add 0.2 Ω
additional errors.
Note
[4]
: Use the 2-wire resistance function.
Note
[5]
: Q marks the optional quick test points.
