Appendix Test Record Form RIGOL
DM3058/DM3058E Performance Verification Guide
5
Frequency Gain
Signal
Effective
Value
Signal
Frequency
Quick
Test
Range
1-year Test Limit
Test
Result
Upper Limit
Lower Limit
200 mV
20 Hz
200 mV
20.0620 Hz
19.9380 Hz
200 mV
1 MHz
Q
[1]
200 mV
1.00016 MHz
0.99984 MHz
Note
[1]
: Q marks the optional quick test point.
Capacitance Gain
Range
[1]
Test Signal
Quick
Test
1-year Test Limit
Test
Result
Upper Limit
Lower Limit
2.000 nF
2 nF
Q
[2]
2.080 nF
1.920 nF
20.00 nF 20 nF 20.30 nF 19.70 nF
200.0 nF
200 nF
203.0 nF
197.0 nF
2.000 μF 2 μF Q 2.030 μF 1.970 μF
200.0 μF
200 μF
203.0 μF
197.0 μF
10000 μF 10000 μF 10250 μF 9750 μF
Note
[1]
: Specifications are obtained under "REL" operation.
Note
[2]
: Q marks the optional quick test points.
