Rigol DM3068

RIGOL Appendix
4 DM3068 Performance Verification Guide
200.0000V 200V 45Hz ±120mV ±200mV ±220mV
200V 20kHz Q ±120mV ±200mV ±220mV
200V 50kHz ±280mV ±340mV ±400mV
200V 100kHz ±1.26V ±1.36V ±1.36V
750.000V 320V 45Hz ±278mV ±449mV ±481mV
320V 20kHz Q ±278mV ±449mV ±481mV
320V 50kHz ±620mV ±759mV ±855mV
320V 100kHz ±2.36V ±2.52V ±2.52V
750V 10kHz Q ±450mV ±750mV ±825mV
Note
[1]
: The AC filter is set to "Slow".
Note
[2]
: Q marks the optional quick test points.
AC Current Gain
Range
[1]
Test Signal
Input
Frequency
Quick
Test
[3]
Allowable Error Range Test Result
24 hours 90 days 1 year 24 hours 90 days 1 year
200.0000μA
200μA 1kHz Q ±420nA ±420nA ±420nA
200μA 5kHz ±420nA ±420nA ±420nA
200μA 10kHz ±2.1μA ±2.1μA ±2.1μA
2.000000mA
2mA 1kHz Q ±3.2μA ±3.2μA ±3.2μA
2mA 5kHz ±3.2μA ±3.2μA ±3.2μA
2mA 10kHz ±9μA ±9μA ±9μA
20.00000mA 20mA 1kHz Q ±42μA ±42μA ±42μA
20mA 5kHz ±42μA ±42μA ±42μA
20mA 10kHz ±210μA ±210μA ±210μA
200.0000mA 200mA 1kHz Q ±280μA ±280μA ±280μA
200mA 5kHz ±280μA ±280μA ±280μA
200mA 10kHz ±900μA ±900μA ±900μA
10mA 10kHz Q ±520μA ±520μA ±520μA
2.000000A 2A 1kHz Q ±4.2mA ±4.2mA ±4.2mA
