Rigol DM3068

Appendix RIGOL
DM3068 Performance Verification Guide
5
2A 5kHz ±4.2mA ±4.2mA ±4.2mA
10.00000A
[2]
10A 1kHz ±23mA ±25mA ±25mA
Note
[1]
: The AC filter is set to "Slow".
Note
[2]
: For continuous currents greater than DC 7A or AC RMS 7A, close the circuit for 30 seconds and then open the circuit for 30 seconds.
Note
[3]
: Q marks the optional quick test points.
Frequency Gain
Signal Effective
Value
Signal
Frequency
Quick Test
[1]
Range
Allowable Error Range Test Result
24 hours 90 days 1 year 24 hours 90 days 1 year
20mV 98Hz 200mV ±4.9mHz ±5.88mHz ±6.86mHz
200mV 500kHz Q 2V ±25Hz ±30Hz ±35Hz
Note
[1]
: Q marks the optional quick test point.
Capacitance Gain
Range
[1]
Test Signal Quick Test
[2]
Allowable Error Range Test Result
1 year 1 year
2.000nF 2nF Q ±90pF
20.00nF 20nF ±260pF
200.0nF 200nF ±2.6nF
2.000uF 2uF ±26nF
20.00uF 20uF ±260nF
200.0uF 200uF ±2.6μF
2.000mF 2mF ±26μF
20.00mF 20mF Q ±260μF
100.0mF 100mF ±3.2mF
Note
[1]
: Specifications are obtained under "REL" operation.
Note
[2]
: Q marks the optional quick test points.
