Chapter 1 Test Preparations RIGOL
DP1308A Performance Verification Manual
1-3
Recommended Test Devices
Please use the recommended test devices in Table 1-1 to test the performance
specifications of DP1308A. If these devices are not present, use devices that fulfill the
“Performance Requirement” in the table below instead.
Table 1-1 Recommended Test Devices
Instrument Performance Requirement
Recommended
Instrument
Digital
Oscilloscope
Bandwidth: ≥100 MHz
Minimum Vertical Scale: ≤2mV
Bandwidth Limit: ≥20MHz
RIGOL DS1102E
Digital
Multimeter
Reading Resolution: 6
bit
RIGOL DM3068
Agilent 3458A
Agilent 34411A
RMS Voltmeter
Sensitivity: 1mV
Bandwidth: ≥10MHz
Agilent 3400A
Agilent 3458A
Programmable
Electronic Load
300W Agilent 6060B
AC Source Adjustment Rate >1% Agilent 6811B
Current
Monitoring
Resistor
0.1Ω (Accuracy: 0.1%
Drift: 10ppm)
——
