RIGOL Chapter 3 Constant Current Tests
DP1308A Performance Verification Manual
3-6
9. Compare the measurement results with the specification in “Appendix B:
Specifications”.
10. Repeat steps 1 to 9 to test the CC linear adjustment rates of the other two output
channels.
Table 3-2 Setting and specification of CC linear adjustment rate test
Channel +6V/5A +25V/1A -25V/1A
Voltage (V) 6.3 26.25 -26.25
Current (A) 5 1 1
Electronic Load
Voltage (V)
6 25 -25
Specification <0.01%+250uA
