RM-DP-1 Rack Mount Kit Installation Guide 3
Product Overview
This product is used to rack mount the DP1000 series (DP1308A or DP1116A) programmable linear DC
power to a standard 19-inch cabinet. Note that this manual takes DP1308A as an example for
demonstration.
Parts List
No.
Name
Qty.
Part Number
Description
1-1
Top Guard Strip
1
RM-DP-1-01
1-2
Bottom Guard Strip
1
RM-DP-1-02
1-3
Front Guard Board
1
RM-DP-1-03
1-4
Instrument Fixing Part
2
RM-DP-1-04
1-5
Instrument Interconnector
2
RM-DP-1-05
1-6
Side Beam
2
RM-DP-1-06
1-7
Side Beam Fixing Part
2
RM-DP-1-07
1-8
Rear Support Stand
1
RM-DP-1-08
2-1
M4 Screw
14
RM-SCREW-01
M4X6 Phil-Slot Pan Head Machine
Screw Nail
2-2
M6 Screw
16
RM-SCREW-02
M6X16 Phil-Slot Pan Head Machine
Screw Nail
2-3
M6 Nut
16
RM-SCREW-03
M6X5 Square Machine Female Screw
Contain Lock Blade
2-4
M4 Countersunk Head Screw
8
RM-SCREW-04
M4X6 Cross Recessed Countersunk
Head Machine Screw Nail
