RIGOL
DP800 快速指南 17
表 4 用户界面说明
编号
说明
1
通道编号
2
通道输出电压
/
电流
3
通道输出状态
4
通道输出模式
5
状态栏，显示系统状态标志。
：打开过温保护。
：前面板已锁定。
：网络已连接。
：已识别 USB 设备。
：打开蜂鸣器。
：关闭蜂鸣器。
：仪器工作在远程模式。
6
实际输出电压
7
实际输出电流
8
实际输出功率
9
电压、电流设置值
10
过压保护、过流保护设置值
11
菜单栏
提示
当前显示模式为“普通”或“波形”时，按前面板 ，可在当前显示模式和表盘显
示模式之间切换。
