RIGOL Chapter 2 Command System
2-214 MSO7000/DS7000 Programming Guide
:TRIGger:FLEXray:SOURce
Syntax
:TRIGger:FLEXray:SOURce <source>
:TRIGger:FLEXray:SOURce?
Description
Sets or queries the trigger source of FlexRay trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D
11|D12|D13|D14|D15|CHANnel1|CHANnel2
|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:FLEXray:SOURce CHANnel2 /*Sets the trigger source to CH2.*/
:TRIGger:FLEXray:SOURce? /*The query returns CHAN2.*/
:TRIGger:FLEXray:WHEN
Syntax
:TRIGger:FLEXray:WHEN <cond>
:TRIGger:FLEXray:WHEN?
Description
Sets or queries the trigger condition of FLEXray trigger.
Parameter
Name
Type
Range
Default
<cond>
Discrete
{FRAMe|SYMBol|ERRor|TSS}
FRAMe
Remarks
 FRAMe: triggers on the frame of the FlexRay bus.
 SYMBol: triggers on the Channel Idle Delimiter (CID), Collision Avoidance
Symbol (CAS), Media Access Test Symbol (MTS), and Wakeup Pattern (WUP) of
the FlexRay bus.
 ERRor: triggers when an error occurs to the FlexRay bus, including header CRC
error and frame CRC error.
 TSS: triggers on the transmission start sequence of the FlexRay bus.
Return
Format
The query returns FRAM, SYMB, ERR, or TSS.
Example
:TRIGger:FLEXray:WHEN FRAMe /*Sets the trigger condition to FRAMe.*/
:TRIGger:FLEXray:WHEN? /*The query returns FRAM.*/
