Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-23
:BUS<n>:SPI (Option)
The :BUS<n>:SPI commands are used to set relevant parameters for SPI decoding.
Command List:
 :BUS<n>:SPI:SCLK:SOURce
 :BUS<n>:SPI:SCLK:SLOPe
 :BUS<n>:SPI:MISO:SOURce
 :BUS<n>:SPI:MISO:POLarity
 :BUS<n>:SPI:MOSI:SOURce
 :BUS<n>:SPI:MOSI:POLarity
 :BUS<n>:SPI:DBITs
 :BUS<n>:SPI:ENDian
 :BUS<n>:SPI:MODE
 :BUS<n>:SPI:TIMeout:TIME
 :BUS<n>:SPI:SS:SOURce
 :BUS<n>:SPI:SS:POLarity
:BUS<n>:SPI:SCLK:SOURce
Syntax
:BUS<n>:SPI:SCLK:SOURce <source>
:BUS<n>:SPI:SCLK:SOURce?
Description
Sets or queries the clock source of SPI decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|
D12|D13|D14|D15|CHANnel1|CHANnel2|CHAN
nel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:BUS1:SPI:SCLK:SOURce D0 /*Sets the clock source of SPI decoding to D0.*/
:BUS1:SPI:SCLK:SOURce? /*The query returns D0.*/
