RIGOL Chapter 2 Command System
2-216 MSO7000/DS7000 Programming Guide
:TRIGger:IIS:SOURce:CLOCk
Syntax
:TRIGger:IIS:SOURce:CLOCk <source>
:TRIGger:IIS:SOURce:CLOCk?
Description
Sets or queries the clock source of the I2S trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D
10|D11|D12|D13|D14|D15|CHANnel1|
CHANnel2|CHANnel3|CHANnel4|EXT}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13,
D14, D15, CHAN1, CHAN2, CHAN3, CHAN4, or EXT.
Example
:TRIGger:IIS:SOURce:CLOCk CHANnel2 /*Sets the clock source to D0.*/
:TRIGger:IIS:SOURce:CLOCk? /*The query returns CHAN2.*/
:TRIGger:IIS:SOURce:DATA
Syntax
:TRIGger:IIS:SOURce:DATA <source>
:TRIGger:IIS:SOURce:DATA?
Description
Sets or queries the data source of the I2S trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D
10|D11|D12|D13|D14|D15|CHANnel1|
CHANnel2|CHANnel3|CHANnel4|EXT}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13,
D14, D15, CHAN1, CHAN2, CHAN3, CHAN4, or EXT.
Example
:TRIGger:IIS:SOURce:DATA CHANnel2 /*Sets the data source to CH2.*/
:TRIGger:IIS:SOURce:DATA? /*The query returns CHAN2.*/
:TRIGger:IIS:SOURce:WSELect
Syntax
:TRIGger:IIS:SOURce:WSELect <source>
:TRIGger:IIS:SOURce:WSELect?
Description
Sets or queries the audio channel of the I2S trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D
10|D11|D12|D13|D14|D15|CHANnel1|
CHANnel2|CHANnel3|CHANnel4|EXT}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13,
D14, D15, CHAN1, CHAN2, CHAN3, CHAN4, or EXT.
Example
:TRIGger:IIS:SOURce:WSELect CHANnel2 /*Sets the audio channel to CH2.*/
:TRIGger:IIS:SOURce:WSELect? /*The query returns CHAN2.*/
