Rigol DS1000Z-E Series Performance Verification Guide

RIGOL Chapter 2 Performance Verification Test
DS1000Z-E Performance Verification Guide
2-4
200 mV/div, 500 mV/div, 1 V/div, 2 V/div, 5 V/div and 10 V/div respectively.
2) Adjust the output voltage of Fluke 9500B to 3 × the current vertical scale and -3 × the
current vertical scale respectively.
3) Repeat steps 3 to 7 and record the test results.
4) Calculate the relative error of each vertical scale: |(Vavg1 - Vavg2) - (Vout1 - Vout2)|/
Full Scale × 100%.
10. Turn off CH1. Test the relative error of each scale of CH2 using the method above and record the
test results.
Test Record Form
Channel
Vertical
Scale
Test Result
Limit Pass/Fail
Vavg1
Vavg2
Calculation Result
[1]
CH1
1 mV/div
≤ 4%
2 mV/div
5 mV/div
10 mV/div
≤ 3%
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
2 V/div
5 V/div
10 V/div
CH2
1 mV/div
≤ 4%
2 mV/div
5 mV/div
10 mV/div
≤ 3%
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
2 V/div
5 V/div
10 V/div
Note
[1]
: The calculation formula is |(Vavg1 - Vavg2) - (Vout1 - Vout2)|/Full Scale × 100%; wherein, Vout1 and Vout2
are 3 × the current vertical scale and -3 × the current vertical scale respectively.
