RIGOL
User’s Guide for DS1000B series
4. Digital Filter
Press CH1→ Digital Filter to display the digital filter menu.
Figure 2-9 Turn off digital filter
Figure 2-10 Turn on digital filter
Turn the digital filter on or off as shown in the following figure. Turn (
) knob
to adjust the upper and lower limit of frequency after turning on the digital filter.
Turn On
Digital Filter
Turn Off
Digital Filter
To Next Page
