Chapter 1 Quick Start RIGOL
MSO1000Z/DS1000Z User’s Guide 1-21
11. Trigger Level
 When an analog channel is selected as the trigger source, you need to set a
proper trigger level.
 The trigger level label
is displayed at the right of the screen and the
trigger level value is displayed at the upper-right corner of the screen.
 When using TRIGGER
LEVEL to modify the trigger level, the trigger
level value will change with the up and down of
.
Note: In slope trigger, runt trigger and window trigger, two trigger level labels
(
and ) are displayed.
12. CH1 Vertical Scale
 Display the voltage value per grid of CH1 waveform vertically.
 Press CH1 to select CH1, and use VERTICAL
SCALE to modify this
parameter.
 The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
13. Analog Channel Label/Waveform
Different channels are marked with different colors and the colors of the channel
label and waveform are the same.
14. CH2 Vertical Scale
 Display the voltage value per grid of CH2 waveform vertically.
 Press CH2 to select CH2, and use VERTICAL
SCALE to modify this
parameter.
 The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
15. CH3 Vertical Scale
 Display the voltage value per grid of CH3 waveform vertically.
 Press CH3 to select CH3, and use VERTICAL
SCALE to modify this
parameter.
 The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
16. CH4 Vertical Scale
 Display the voltage value per grid of CH4 waveform vertically.
 Press CH4 to select CH4, and use VERTICAL
SCALE to modify this
parameter.
 The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
17. Message Box
Display the prompt messages.
