Rigol DS1104Z Plus User Manual

RIGOL Chapter 2 To Set the Vertical System
2-6 MSO1000Z/DS1000Z User’s Guide
Select "A
a
" using and press down to switch it to "
a
A". Select "C" using
and press down
to input the character. Use the same method to input "hn1".
After finishing the input, press OK to finish the editing. If the Display is enabled,
the label
will be displayed at the left of CH1 waveform.
To modify or delete the input character, press Name to select the "Name Input Area"
and use
to select the character to be modified or deleted. Enter the desired
character or press Delete to delete the character selected.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
