Appendix Test Record Form RIGOL
DS1000Z-E Performance Verification Guide
1
Appendix Test Record Form
RIGOL DS1000Z-E Series Digital Oscilloscope
Performance Verification Test Record Form
Model:
Tested by:
Test Date:
Impedance Test
Channel
Vertical Scale
Test Result
Limit
Pass/Fail
CH1
100 mV/div
0.99 MΩ to 1.01 MΩ
500 mV/div
CH2
100 mV/div
500 mV/div
DC Gain Accuracy Test
Channel
Vertical
Scale
Test Result
Limit Pass/Fail
Vavg1 Vavg2
Calculation
Result
[1]
CH1
1 mV/div
≤ 4%
2 mV/div
5 mV/div
10 mV/div
≤ 3%
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
2 V/div
5 V/div
10 V/div
CH2
1 mV/div
≤ 4%
2 mV/div
5 mV/div
10 mV/div
≤ 3%
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
2 V/div
5 V/div
10 V/div
Note
[1]
: The calculation formula is |(Vavg1 - Vavg2) - (Vout1 - Vout2)|/Full Scale × 100%; wherein, Vout1 and Vout2
are 3 × the current vertical scale and -3 × the current vertical scale respectively.
Bandwidth Test
Channel
Vertical
Scale
Test Result
Limit Pass/Fail
Vrms1 Vrms2
Amplitude
Loss
[1]
CH1
100 mV/div
-3 dB to 3 dB
500 mV/div
CH2
100 mV/div
500 mV/div
Note
[1]
: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrms1).
