Rigol DS4000 Series

Chapter 1 Disassemble and Assemble RIGOL
MSO4000/DS4000 Service Guide 1-13
Tip
Pay attention to the connecting positions of the keyboard cables and the probe
pinboard cables
before removing them to avoid incorrect connection or incomplete
connection when assembling the instrument.
