Rigol DS4024 Service Guide

Chapter 1 Disassemble and Assemble RIGOL
MSO4000/DS4000 Service Guide
1-1
Chapter 1 Disassemble and Assemble
Disassemble and Assemble Notices
Notices:
 Do not disassemble the instrument unless for working requirement.
 Only authorized personnel can disassemble the instrument.
 Cut off the power supply before disassembling the instrument.
 Please wear anti-static wrist strap or make other anti-static precaution when
disassembling the instrument.
 Please use proper tools and follow the correct steps.
 Take care not to deform the metal structure and be scuffed when disassembling
the metal structures.
Tools Required:
 Phillips screwdriver T10
 BNC socket
 5mm hexagon socket
WARNING
Make sure that the power supply is cut off before disassembling the
instrument. Only personnel with relative training or relative qualification
certification can disassemble the instrument.

Rigol DS4024 Specifications

General

Brand	Rigol
Model	DS4024
Category	Test Equipment
Language	English
