Chapter 1 Disassemble and Assemble RIGOL
MSO4000/DS4000 Service Guide 1-3
Table 1-1 Part Explanation of MSO4000/DS4000 Exploded View
No.
Part Name
No.
Part Name
1
Front Metal Plate
24
Power PCB Board
2
Rear Metal Cover
25
Heating Tube
3
Handle Groove on Rear Metal
Cover
26 Power Shield
4
LCD Frame
27
Interface PCB Board
5
Navigation Knob (Inner Layer)
28
USB HOST Interface
6
Navigation Knob (Outer Layer)
29
USB DEVICE Interface
7
Rear Cover
30
LAN Interface
8
Handle
31
Video Output Interface
9
Front Panel
32
BNC Connector
10 Main Rear Supporting Leg 33
PCB Board of Keys at the Right
Side of the Screen
11
Supporting Block of Keys at the
Top
34 Main Key PCB Board
12
Large Knob
35
Probe Pinboard
13 Small Knob 36
PCB Board of Keys at the Left
Side of the Screen
14
Front Non-slip Pad
37
Screen Pinboard PCB Board
15
Presser of Keys at the Top
38
Fan
16
Shield
39
Power Socket
17
Main Keys
40
LCD
18
Keys at the Left Side of the
Screen
41 Auxiliary Rear Supporting Leg
19
Keys at the Right Side of the
Screen
42 Rear Supporting Foot
20
Keys at the Top
43
Rear Supporting Foot Block
21 Power Key 44
Rear Supporting Foot Rotating
Shaft
22 Main Board 45
Torx Pan Head Screw Assembly
#FW3*6
23
PCB Board of Keys at the Top
46
Blot
The recommended disassemble procedures are as follows:
To Disassemble the Rear Cover  To Disassemble the Rear Metal Cover  To
Disassemble the Fan and Power Socket  To Disassemble the Power Supply and
Interface Board  To Disassemble the Front Panel and Knobs  To Disassemble the
LCD and Pinboard  To Disassemble the Keyboards  To Disassemble the Main Board
