Rigol DS4024 Service Guide

RIGOL Chapter 1 Disassemble and Assemble
1-6 MSO4000/DS4000 Service Guide
Tip
 Pay attention to the connecting positions of the power cables and data cable
before removing them to avoid incorrect connection or incomplete connection
when assembling the instrument.
 Insert the cables to the corresponding ports on the main board before
assembling the rear metal cover.

Rigol DS4024 Specifications

General

Brand	Rigol
Model	DS4024
Category	Test Equipment
Language	English
