Rigol DSA1030A series Performance Verification Guide

Chapter 1 Overview RIGOL
DSA1000A/DSA1000 Performance Verification Guide
1-1
Chapter 1 Overview
Test Preparations
Before the test, make the following preparations.
1. Warm the spectrum analyzer up for at least 30 minutes.
2. Make sure that the instrument is within the calibration period (the calibration period is 1 year)
and perform self-calibration on the spectrum analyzer (press System  Calibrate  Cal Now
and the spectrum analyzer performs self-calibration immediately using the internal calibration
source).
3. The test devices required are as shown in the table below.
Table 1-1 The test devices required
Device Specification Qty. Recommended
Signal Generators
Amplitude accuracy: ±0.6 dB
Single-sideband phase noise: <-126 dBc/Hz
2 Agilent N5181A
Frequency Counter
Frequency range: 10 MHz ± 100 Hz
Support single trigger and external reference input
Gate time: ≥10 s
Frequency resolution: 10 digits/s
1 Agilent 53181A
Power Meter
Compatible with Agilent E9304A power sensor
dB relative mode
Resolution: 0.001 dB
Reference accuracy: ±1.2%
1 Agilent N1913A
Power Sensor
Frequency range: 9 kHz to 18 GHz
Maximum SWR:
1.13 (9 kHz to 2 GHz)
1.19 (2 GHz to 14 GHz)
1.22 (14 GHz to 16 GHz)
1.26 (16 GHz to 18 GHz)
Amplitude range: 1 nW to 100 mW (-60 dBm to +20 dBm)
1 Agilent E9304A
Power Divider
Frequency range: 9 kHz to 13.2 GHz
Insert loss: 6 dB, rated
Output track: <0.25 dB
Equivalent output SWR: <1.22:1
1 Agilent 11667A
Low-pass Filter
[1]
Cut-off Frequency: 1 GHz 1
--
Attenuator/Switch
Driver
Compatible with Agilent 8494H and 8496H programmable
step attenuator
1 Agilent 11713B
