Chapter 2 Front Panel Operation RIGOL
User’s Guide for DSA800/E Series
Table 2-30 Start Line for T-Power Measurement
Parameter Description
Default 0 us
Range 0 us to Stop Line
Unit ks, s, ms, us, ns, ps
Knob Step Sweep Time/600, Min = 1us
Direction Key Step in 1-1.5-2-3-5-7.5 sequence
5. Stop Line
Set the right margin (in time unit) of T-Power measurement. The data
calculated under this measurement is between the start line and stop line.
You can use the numeric keys, knob or direction keys to modify this
parameter.
Table 2-31 Stop Line for T-Power Measurement
Default 37.5 ms
Range Start Line to Sweep Time
Unit ks, s, ms, us, ns, ps
Knob Step Sweep Time/600, Min = 1us
Direction Key Step in 1-1.5-2-3-5-7.5 sequence
