Chapter 3 Remote Control RIGOL
User’s Guide for DSA800/E Series
2. Remote Control via LAN
1) Connect the devices
Connect the analyzer to your LAN.
2) Configure LAN parameters
Select LAN interface according to the description in “LAN” of “I/O
Settings”.
3) Search device resource
Start-up Ultra Sigma and click
. Then, click in
the pop-up window and the software starts searching for the analyzer
resources connected to LAN. When a LAN resource is found, its name will
be displayed in the resource box on the right side of the panel. Select the
desired resource and click
to add the resource. As shown in
the figures below.
(a)
To Next Page
