RIGOL Chapter 2 Performance Verification Test
2-6 DSG800 Performance Verification Guide
Reference Value -80 dBm
DSG800 Output
Frequency
Signal Analyzer
Measurement Value A3
Global
Error
[2]
Amplitude
Accuracy
[3]
Limit
Pass/
Fail
103 kHz
≤ 1.1 dB,
≤ 0.7 (typ.)
1.03 MHz
50.03 MHz
503 MHz
1.403 GHz (Only for
DSG815)
1.903 GHz (Only for
DSG830)
2.493 GHz (Only for
DSG830)
2.903 GHz (Only for
DSG830)
Note:
[1] System Error = A2 - A1
[2] Global Error = A3 - Reference Value
[3] Amplitude Accuracy = |Global Error - System Error|
