Rigol DSG800 Series Performance Verification Guide

RIGOL Appendix
4 DSG800 Performance Verification Guide
FM Test:
DSG800 Output
Frequency
Item
Measurement
Value
Calculation
Result
Limit
Pass/
Fail
1 GHz
Modulation
Accuracy
[1]
< Modulation Frequency
Deviation Setting × 2% + 20 Hz
Distortion
[2]
< 2% (typ.)
Note:
[1] Modulation Accuracy = |(Pk - Pk) / 2 - 50 kHz|
[2] Distortion = Distortion Value in the FM Analog Demodulation Test Interface
ØM Test:
DSG800 Output
Frequency
Item
Measurement
Value
Calculation
Result
Limit
Pass/
Fail
1 GHz
Modulation
Accuracy
[1]
< Modulation Phase Deviation
Setting × 1% + 0.1 rad
Distortion
[2]
< 1% (typ.)
Note:
[1] Modulation Accuracy = |(Pk - Pk) / 2 - 5 rad|
[2] Distortion = Distortion Value in the ØM Analog Demodulation Test Interface
Pulse Modulation Test:
DSG800 Output
Frequency
Item
Measurement
Value
Calculation
Result
Limit
Pass/
Fail
1 GHz
On/Off
Ratio
> 70 dB
2 GHz (Only for
DSG830)
On/Off
Ratio
> 70 dB
Note: [1] Calculation Result = -Delta
10MHz Reference Input Amplitude Range Test:
Amplitude Measurement
Value A1
Amplitude Measurement
Value A2
A1 to A2 Specification
Pass/
Fail
0 dBm to +10 dBm
