RIGOL Chapter 18 Store and Load
18-18 MSO5000 User Guide
SourceB
CH1
Offset
0 V
Scale
500 mV
A× B
Operation
OFF
SourceA
CH1
SourceB
CH1
Offset
0 U
Scale
500 mU
A÷B
Operation
OFF
SourceA
CH1
SourceB
CH1
Offset
0 U
Scale
500 mU
FFT
Operation
OFF
Source
CH1
Offset
0 dBV
Scale
2 dB
Unit
dBm/dBV
X
Start-End
Start Freq
0 Hz
Stop Freq
10 MHz
Window Function
Hanning
Mode
Trace
View
Full
Peak Search
OFF
Peak Number
5
Threshold
5.5 dB
Excursion
1.8 dB
Table Order
Amp Order
A&&B
Operation
OFF
SourceA
CH1
SourceB
CH1
Wave Size
Medium
Thre.CH1
0 V
Thre.CH2
0 V
Thre.CH3
0 V
Thre.CH4
0 V
Sensitivity
0.3 Div
A||B
Operation
OFF
