Chapter 12 Protocol Decoding RIGOL
MSO8000 User Guide 12-11
Press Separator and rotate the multifunction knob to select the
desired package separator in data transmission, then press down the knob
to select it. You can also press Separator continuously or enable the touch
screen to select it. It can be set to 0A(LF), 0D(CR), 20(SP), or 0(NUL).
6． Display-related setting
Press Display to enter the display setting menu.
âš« Set the display format
Press Format, rotate the multifunction knob to select the display
format of the bus data. Then, press down the knob to select it. You can also
press Format continuously or enable the touch screen to select it. The
available display formats of the bus data are "Hex", "Dec", "Bin", and
"ASCII".
âš« Adjust the vertical position of the bus
Press Position, and then rotate the multifunction knob to adjust the
vertical display position of the bus. You can also rotate Wave Vertical
POSITION to adjust the vertical display position of the bus.
âš« Set the label display
Press Label to enable or disable the label display of the RS232 decoding
bus. When enabled, the bus label "RS232-TX" and/or "RS232-RX" will be
displayed at the upper-left side of the bus (when the bus display is
enabled).
âš« Event table
Press Event Table to enter the event table setting menu. The event table
displays the detailed decoding information in time order in the form of a
table, so as to better observe the long decoded data. The decoding
information includes the decoded data (Tx and/or Rx), the corresponding
line number, time, and error information (Tx and/or Rx).
Note: When the Tx and Rx source channels are set to "OFF", information of
the data line is not displayed in the data table.
➢ Open or close the event table: Press Event Table continuously to
enable or disable the event table. You can also enable the touch screen
to tap the icon at the upper-right corner of the table to close the
event table.
Note:
âš« When you adjust the horizontal time base, the waveform displayed
on the screen will also change, and the total number of lines
containing the decoding information in the event table will also be
changed.
