RIGOL Chapter 19 Store and Load
19-8 MSO8000 User Guide
management interface is displayed automatically. By default, "Local Disk(C)"
is selected.
2) Rotate the multifunction knob or enable the touch screen to open the
internal memory storage interface.
3) Rotate the multifunction knob to select the desired storage location,
and then press down the knob to open it. You can also enable the touch
screen to select the storage location. Rotate the multifunction knob to
select , then press down the knob or enable the touch screen to tap
to go to the previous location.
4) Rotate the multifunction knob to select the file to be loaded (the default
file type is in "*stp" format). Then, the Load menu is enabled. Press Load
to load the selected file. You can also enable the touch screen to operate.
Tip
⚫ Press Ref → More → Import to enter the disk management interface of
reference waveform file load.
⚫ Press Utility → PassFail to enable the pass/fail test function. Then press
Mask → Load to enter the disk management interface of pass/fail test mask
file load.
