Chapter 20 System Utility Function Setting RIGOL
MSO8000 User Guide 20-17
operation type.
9. Save Group
When the Quick shortcut key is set to "Save Group", press Quick on the front
panel to save group.
âš« Operation Type
Press Operation and then rotate the multifunction knob to select "Save
Group". Press down the knob to select it. You can also press Operation
continuously to select among the options, or enable the touch screen to tap
the desired operation type.
âš« Group
Set the Group parameter: press Group and then rotate the multifunction
knob to select "Save Image", "Save Wave", or "Save Setup". Press down
the knob to select the desired one. You can also press Group continuously or
enable the touch screen to select it. You can select any or all of the three
items. The sign indicates that the item has been selected, and
indicates that the item has not been selected.
Screen Saver
When the oscilloscope enters the idle state and holds for a certain period of time, the
screen saver program will be enabled.
Press More → Screen Saver to enter the screen saver setting menu. Press Screen
Saver, then use the multifunction knob to select the screen saver type, and
then press down the knob to select the type. You can also press Screen Saver
continuously or enable the touch screen to select it. The available screen saver types
include "Off", "Picture", and "Text". The screen saver program is disabled by default.
1. Select the Screen Saver
âš« If you select "Off" under Screen Saver, it indicates that the screen saver is
disabled.
âš« If you select "Picture" under Screen Saver, press Select Picture to select
the file. The file types include "*.png", "*.bmp", "*.jpg", and "*.tif".
âš« If you select "Text" under Screen Saver, press Text, and then the
filename input interface is displayed, e.g. inputting "RIGOL Scope". For
details, refer to descriptions in "To Create a Folder".
2. Set the Wait Time
Press Time to Start, then directly rotate the multifunction knob to set the
screen saver time. Also, you can use the pop-up numeric keypad to input the
screen saver time. The available range is from 1 min to 999 min.
To Next Page
