RIGOL Chapter 6 System Function
6-8 RSA3000 User Guide
4. User Key
Defines an associated function for the User key on the front panel. The
definition method is as described below. After that, pressing User in any
operation interface can quickly enable the defined function.
⚫ Press User Key to select "On";
⚫ Open the function menu that needs to be defined. For example, press
System → Display → Display Line;
Press User and the definition is finished. At this time, User Key turns off
automatically.
5. SCPI Display
When you use the SCPI commands to control the instrument remotely, turning
on the SCPI Display will go to the specified menu of the corresponding
command; turning off the SCPI Display will not go to the specified menu.
Messages
Press this key, and then a prompt message dialog box will be displayed. You can
press the corresponding softkey to select to view all the messages, the messages
that have been read or not read. You can also use the touch screen or the externally
connected mouse to tap or click the specified icon in the prompt message dialog box.
1. Select All
Selects all the displayed messages.
2. Select Read
Only selects the messages that have been read.
3. Select Unread
Only selects the messages that have not been read.
4. Delete
Deletes the selected messages.
5. Query All
Views all the displayed messages.
6. Query Read
Only views the messages that have been read.
7. Query Unread
Only views the messages that have not been read.
