Ringway TD90 - Module Assembly

2
Insert the Hi-Hat stand(the shorter one)
into the rack clamp and tighten the
T-screw.
3
1.Take out the wing nut and felt
washer.
2.Place the cymbal over the tilter
peg. put the felt washer and
wing nut onto the cymbal. Tilt
the cymbal to your preference.
1
1.Insert the module into the rack
clamp.
2.Tighten the T-screw.
Module Assembly
6
felt washer
wing nut
Hi-Hat Cymbal
Crash Cymbal
Electronic Drum
