To Next PageTo Next PageWhat should the voltage reading be across the Blue and Yellow transformer wires on a Rinnai Indoor Fireplace?
When measuring the voltage across the Blue and Yellow transformer wires of your Rinnai Indoor Fireplace, you should read between 130 and 185 VAC.
What voltage should I read across the Gray to Gray transformer wires on my Rinnai Indoor Fireplace?
When measuring voltage across the Gray to Gray transformer wires on your Rinnai Indoor Fireplace, the reading should be between 110 and 120 VAC.
What voltage should I read across the White to White transformer wires on my Rinnai Indoor Fireplace?
When measuring the voltage across the White to White transformer wires of your Rinnai Indoor Fireplace, you should read between 98 and 105 VAC.
What resistance reading should I get across the Blue and Red sparker board wires on a Rinnai Indoor Fireplace?
When reading resistance across the two lugs where the blue and red wires connect on the sparker board of your Rinnai Indoor Fireplace, you should measure between 100k and 120k ohms.
What should the voltage reading be across the Red to Red transformer wires on a Rinnai Indoor Fireplace?
When measuring the voltage across the Red to Red transformer wires on your Rinnai Indoor Fireplace, you should read between 28 and 50 VAC.
What voltage reading should I see across the Black and Blue transformer wires in my Rinnai Indoor Fireplace?
When measuring the voltage across the Black and Blue transformer wires of your Rinnai Indoor Fireplace, you should read between 10 and 15 VAC.
Explains the meaning of safety alert symbols like Danger, Warning, and Caution.
Provides guidance on how to use the service manual effectively for repairs.
Information on how to contact Rinnai Technical Services for assistance with servicing issues.
Lists essential tools required for servicing the appliance, including meters and wrenches.
Details how to retrieve stored fault codes from the appliance's control board.
Lists and defines various fault codes and their corresponding analog/digital LED indicators.
Addresses common troubleshooting issues not directly related to fault codes, like no operation or heating.
Provides detailed troubleshooting steps and electrical specifications for the RHFE-201FA model.
Details troubleshooting procedures and electrical specifications for RHFE-263FA, FAII, and RFA models.
Outlines troubleshooting steps and electrical specifications for RHFE-202FTA and RHFE-265FTA models.
Covers troubleshooting for RHFE-431FA/WTA and RHFE-556FA/WTA/FTRA series appliances.
Provides troubleshooting guidance and electrical specifications for RHFE-433RFA and RHFE-558RFA models.
Details troubleshooting steps and electrical specifications for RHFE-434FTA and RHFE-559FTA models.
Includes troubleshooting procedures, fault finding charts, and electrical checks for the RHFE-551FA.
Covers troubleshooting steps, fault finding charts, and electrical specifications for the RHFE-1001FA.
Provides troubleshooting guidance and electrical specifications specific to the RHFE-1001FA/VA model.
Details troubleshooting procedures and electrical specifications for RHFE-1004FA, RFA, and FTA models.
Procedure for setting gas pressure for RHFE-201FA and RHFE-263FA/FAII models at different altitudes.
Procedure for setting gas pressure for RHFE-201RFA and RHFE-263RFA models at different altitudes.
Procedure for setting gas pressure for RHFE-202FTA and RHFE-265FTA models at different altitudes.
Procedure for setting gas pressure for RHFE-431 and RHFE-556 series models at different altitudes.
Procedure for setting gas pressure for RHFE-433RFA and RHFE-558RFA models at different altitudes.
Procedure for setting gas pressure for RHFE-433RWTA and RHFE-558RWTA models at different altitudes.
Procedure for setting gas pressure for RHFE-434FTA and RHFE-559FTA models at different altitudes.
Procedure for setting gas pressure for RHFE-1004FA models at different altitudes.
Procedure for setting gas pressure for RHFE-1004RFA and RHFE-1004FTA models at different altitudes.
Procedure for installing a new PC board and setting codes for specific Rinnai models.
Steps for installing a new PC board and setting gas type/altitude for specific Rinnai models.
Procedure for installing a new PC board and setting dipswitches for RHFE-433RWTA/558RWTA.
Instructions for PC board replacement and setting altitude/gas type for specific Rinnai models.
General
